eu health green pass code verification system

production description

◆the embedded linux operating system has an overwhelming advantage in reliability and stability compared with android

◆support output real-time video stream to other devices, integrated face capture, comparison and identification, infrared temperature measurement functions

◆support european health code information verification function

◆ abnormal temperature alarm: non-contact frontal temperature detection within one second, temperature measurement distance 30-70cm, temperature measurement error range ±0.5℃, abnormal temperature linkage external sound and light alarm

◆ industrial design, adjustable pitch angle, left and right rotation

◆ support in vivo detection, effectively prevent photos, videos and other deception

◆ using deep learning algorithm, face database of 10,000

◆ flexible face template import, support single, batch image file import and real-time capture import

◆ face types such as visitors, whitelists, and blacklists are supported

◆ support linkage output of recognition results and voice broadcast

◆ it can be widely used in access control channels, wall hanging attendance and temperature measurement screening and other scenarios

◆support check whether the health code is valid


model

few6133f01b

screen

size

7 inch, full-angle ips lcd screen

resolution

1280x800

  camera

type

design of double camera

sensor

1/2.8" cmos

resolution

1080p@30fps

lens

6mm*2

temperature detection

detect area

forehead

temperature environment

0-30℃(advice 16-30℃)

scope of detection

34-42℃

temperature  distance

30-70cm

error range

±0.5℃

temperature response

≤1s

face recognition

detection type

support lving face detection, effective prevention of print photos,  phone photos and video spoofing

face detection number

0.5-2m, support detection target size filter adjustment

recognition face size

pupils distance ≥  60 pixels; face pixel ≥150 pixels

face database capacity

support built-in ≤ 10000 faces2w face library optional; support black/white list

posture

support side face filter function, pitching 20°, about 20° can be comparable

shelter

recognizable with ordinaryglasses and  short bangs hair

helmet testing

support

mask wearing test

support

expression

recognizable with  slight expression

response speed

≤1s

face exposure

support

local storage

support storage of more than 100,000 capture and recognition records

recognition area

recognition area full image

upload mode

ftp、http、api calling upload

safe mode

authorized user name and password

system upgrade

support remote upgrade

other

/

function


network protocol

ipv4,tcp/ip,ntp,ftp,http ,smtp

access protocol

rtsp

safe mode

authorized user name and password

event linkage

ftp upload, alarm output linkage, wiegand output linkage, voice broadcast

accessories

complementary light

ir light, led white light

health code verification

support eurohealth code verification, code brush status temperature information

recognition module

support ic card  recognize module optional

loudspeaker

support voice broadcast after successful recognition

network module

support built-in wifi module optional

interface

network interface

rj45 10m/100m network adaptative

alarm output

2ch

wiegand input

support

rs485

support

tf card

max.support 128g local-storage

usb

1ch

wiegand interface

support wiegand 26,34 protocol

reset

support

sim slot

support

general

operating temperature

-20°c ~ 55°c(temperature measurement environment 0-30℃, recommended 16-30℃)

operating humidity

0﹪-90﹪

power supply

dc12v

power consumption (max)

≤13w

dimensions(mm)

368.2mm(h)*120mm(w)

weight /pcs(g)

tbd
